Honda Legend (KB1) 2004-2008 (RH Japanese market) Body dimensions

Honda Legend (KB1) 2004-2008 Body dimensions

Body dimensions for restoring the body geometry of Honda Legend (KB1) 2004-2008 are used to verify the body geometry and facilitate the subsequent repair of damaged parts. These measurements are specifically applicable to the right-hand drive versions of Honda Legend for the Japanese market.

A selection of information is available from the factory documentation and vehicle measurement database in Japanese for the Honda Legend 2004-2008 with right-hand drive, including body dimensions and control points (chassis diagrams, upper body datasheet, underbody datasheet).

Upperbody dimensions include pillar widths for inside passenger compartment, door, windshield and rear window. Choice of Edge-of-hole or center-of-hole dimensions, widths measured from centerline and individual datum lengths for underbody information, diagonal measurements, deck lid measurements for more extensive and complete collision repairs.

Data sample from the archive


Honda Legend (KB1) 2004-2008 (RH Japanese market) Body dimensions

















Download vehicle dimensions
Honda Legend (KB1) 2004-2008 (RH Japanese market)

Price: $30
